1200×1200mm Heavy-Duty Reinforced Three-Runner Grid Deck Plastic Pallets
This injection-molded plastic pallet features a three-runner base and a ventilated grid top deck, making it ideal for racking and heavy-duty logistics. The solid one-piece construction ensures excellent durability and dimensional stability under load. Built-in steel reinforcements provide strong racking performance, and its structure is optimized for forklift and pallet jack compatibility on all four sides. It is widely used in automated warehouses, cold storage, and export logistics.
Key Features of Three-Runner Grid Deck Plastic Pallets
Structure: 3-runner bottom with grid (ventilated) top deck
Manufacturing Method: One-piece injection molding
Material: HDPE or PP (100% virgin or recycled)
Reinforcement: Optional 4 steel tubes (top) + 6 tubes (bottom)
Entry: 4-way forklift and pallet jack access
Surface: Anti-slip, washable, and hygienic design
Color & Logo: Customizable according to your brand
Why Choose Three-Runner Grid Deck Plastic Pallets?
One-Piece Structure: The deck and runners are formed as an integrated injection-molded pallet with no assembled joints.
Integrated Construction: One-piece molding avoids welded, bolted, or snap-fit connections between the deck and runners.
Structural Consistency: The integrated structure supports stable repeated handling without detachable pallet sections.
Hygienic Flat Deck – Easy-to-clean surface, suitable for food, pharmaceutical, and cold chain applications.
Customizable Options – Available with steel reinforcements, RFID/barcode tracking, logo printing, and more.
Specs
| Size: | 1200X1200X170mm |
| Static Load: | 5000 kg |
| Dynamic Load: | 1500 kg |
| Rack Load: | 1000 kg |
| Molding Method: | One-piece injection molding |
| Fork Entry: | 4-way |
| Color: | Blue (default) / Custom |
Other Available Sizes
Same model, multiple options to meet your needs.
| Size (mm) | Size (mm) | Size (mm) |
| 1000×800×150 | 1200×1000×160 | 1300×1100×160 |
| 1000×1000×160 | 1200×1000×165 | 1300×1200×170 |
| 1000×1200×160 | 1200×1100×160 | 1300×1200×180 |
| 1100×1100×150 | 1200×1200×150 | 1350×1000×170 |
| 1100×1100×160 | 1200×1200×160 | 1400×1100×165 |
| 1200×800×150 | 1200×1200×170 | 1400×1100×175 |
| 1200×800×160 | 1200×1400×170 | 1400×1200×170 |
| 1200×1000×150 | 1300×1100×150 | 1400×1200×175 |
Application
Warehouse Racking Systems –
Compatible with beam racks and drive-in racking for safe vertical storage. Steel reinforcements available for higher load requirements.Cold Chain Logistics –
Ideal for frozen food, seafood, and pharmaceutical cold storage due to its ventilated deck and easy-to-clean surface.Export & International Shipping –
Reusable and robust for global shipping. Standard pallet dimensions fit containers, while the one-piece molded structure supports repeated closed-loop use.- Industrial Closed-Loop Use –
Perfect for reuse in production lines, distribution centers, and automation equipment. Resistant to impact and long-term handling - Food & Beverage Processing –
Hygienic and chemical-resistant design with optional anti-slip and drainage features. Suitable for cleanrooms and wet areas.
Selection notes for reinforced grid deck pallets
This 1200×1200 reinforced three-runner grid deck pallet should be specified by cargo footprint, loaded weight, deck support need, handling equipment and storage method. Reinforcement is one part of the product structure, not a general approval for every racking condition. For beam racking, provide the rack span, support points and loaded pallet details. Compare rackable plastic pallet options.
Buyer FAQ
Why does load distribution matter?
Loads with the same weight can require different deck and base support.
What should be confirmed for racking?
Check the rack, loaded pallet and support condition together.
